SKU:43560625
Hydraulic Gear Pumps from Magister Hydraulics are manufactured with thru-bolt design; Mounting flange and rear cover made of of rolled Cast Iron; SAE B-2 mounting flange; This gear pump has high operational and strength specs. The seals installed, reduce internal flow of the fluid and help to achieve a high volumetric efficiency. Displacement (CID): 0.27-1.70 Cubic Inches; Shaft Type - 3/4" Straight Keyed; Mounting Flange - SAE B-2 Bolts; Outlet Port - SAE 10; Inlet Port - SAE 12; Rotation direction: CW (right) or CCW (left); Cast Iron Rear Cover and Mounting Flange; For more details please check the drawing; Magister Hydraulic Gear Pump is suitable for a variety of mobile equipment applications, such as agriculture, construction, transportation, forestry, garden, etc.
Displacement 0.50 Cubic Inches
Rotation Clockwise
Max. RPM 3500
Flow @2000 RPM 4.32 GPM
Pressure 3600-4350 PSI
Looks well made. There are no markings for rotataion, inlet , or outlet. The ports are both the same size. I would guess they use the same pump for both ccw and cw rotation.
